Wired ConferenceMicrophoneSystemwith Chief Unit/Extension Unit/ReceivingHost

Features

functions;

2. In conjunction with the video switcher, 4 cameras can be connected at the same time to achieveseamless tracking and shooting switching;

3. USB high-speed interface, support USB device access to record conferences, and play audio files inUSB devices;

4. 4.3-inch TFT full Chinese color capacitive touch screen, which can directly set conference mode,tracking shooting, unit address editing, volume adjustment, conference recording and other modes;

5. The system has a variety of conference modes: discussion mode, automatic mode, quantity limit,first in first out, last in first out, voice control mode, chairman mode, full open mode, etc.;

6. The system is embedded in the Web GUI control interface, without installing software, you candirectly log in to the Web GUI through the web page to perform various settings and operations onthe host, supporting Apple iOS/Google Android/Microsoft Windows systems;

7. Support PC software control, can set and operate through USB, network cable, WIFI and direct connection;

8. Support QR code scanning control, you can scan the QR code of the system through IPAD, mobilephone and other mobile communication devices to perform various settings and operations on the host;

9. The host can initiate the unit ID address writing mode, and flexibly increase or decrease the number of units at any time;

10. Built-in 1-way balanced output interface and 1 set of RCA line input and output interface and 1 set of RCA telephone coupler sockets. Used for audio PA output and external audio access;

11. Built-in 4 groups of 8 RJ45 unit interfaces, 1 host cascading interface, a single host can be connected to 100, and the maximum can be connected to 1000 through expansion, support ring power supply, even if the system lines are broken due to faults, it will not be affected. the normal operation of the system;

12. The host supports one key to turn off all unit functions, saving the operation of manually turning off the unit power;
