VP Series

VP05, VP07,VP09,V912,VP15

Product features

With DC protection, overload protection, short-circuit protection, overheating protection, pressure limit protection, soft start protection, the machine performance is safer;

Adopting a large number of high-precision SMD devices, automated production process, product reliability is higher;

Adoption of high-efficiency toroidal transformer with magnetic shielding layer, effective anti-interference;

High-efficiency class H line design, high power, low heat generation, small size;

Automatic variable speed fan, optimised heat dissipation system, making the machine performance more stable;

DSP Features:

Two channel inputs, two channel outputs; 24bit/96KHz sampling frequency; audio matrix mixing; FIR filter makes the speaker frequency response curve close to the perfect value;

Input channel functions are high and low pass filters, delay, phase, mute, noise gate, parametric equalisation;

The output channel functions are high and low pass filters, delay, phase, mute, pressure limit, limiter, parametric equalization;

Voltage limiter whose start time, release time and threshold are adjustable; amplifier radiator temperature detection;

High-pass/low-pass filter, slope and type (Butterworth, Linkwitz-Riley, Bessel) multiple choices -6dB,-12dB,-24dB,-36dB,-48dB, crossover point can be any range;

USB (drive-free) interface to connect to the computer control, RS485 interface to connect to the computer control, RS485 can be more than one connected machine; preset procedures to save 10; user password settings root right;

Users support Windows platform client, software built-in Chinese and English operation interface can be selected;

Screen function display: volume, temperature, can be in the panel knob to call the preset programme;
